PERC 3/DC or PERC 3/DCL Hardware Installation
121
7
Connect SCSI devices.
8
Power on the host system.
9
Run the BIOS Configuration Utility or the WebBIOS Configuration
Utility.
10
Install the operating system software driver.
Step 1—Unpack the PERC 3/DC or PERC 3/DCL
Unpack and install the hardware in a static-free environment. Remove the
controller card and inspect it for damage. If the card appears damaged,
please contact your Dell support representative.
Step 2—Power Down
Turn off the computer and remove the AC power cord. Ensure that the
computer is disconnected from any networks before installing the controller.
Remove the system cover. For information regarding removal of system
covers, please consult the system documentation.
Step 3—Set Jumpers
Make sure the jumper settings on the PERC 3/DC or PERC 3/DCL card are
correct. The jumpers and connectors are shown in Table 9-1.
Ta b l e 9 - 1 . J u m p e r S e t t i n g s
Connector
Description
Type
J2
Channel 1 termination enable
3-pin header
J3
Channel 0 termination enable
3-pin header
J4
Channel 0 internal Wide SCSI
68-pin connector
J5
Channel 1 internal Wide SCSI
68-pin connector
J7
Channel 0 external Wide SCSI
68-pin connector
J8
Serial erasable programmable read-
only memory (EEPROM) port
2-pin header
J9
Onboard BIOS enable
2-pin header
J10
Non-volatile random access memory
(NVRAM) clear
2-pin connector
J11
Serial port connector
3-pin header
