Getting Started
Power Supply Cable
Connect the power cable to the board and plug the other end into a power
outlet. To power up the board, place the power switch (S10) in the ON
position. When power is supplied to the board, the LED (D13)
illuminates.
After the board powers up, the on-board flash memory, which ships
pre-programmed with the factory design, automatically configures the
Stratix II GX device. The CONF DONE LED (D14) illuminates, signaling
that the Stratix II GX device is configured.
1 If the board does not power up after the power cable is
connected, make sure that the power switch (S10) is in the ON
position.
Setting the Clock
Circuit Switches Set the DIP switch S8 and slide switch S9 per the instructions listed in
Table 2–2 .
1 To use the on board oscillator, the slide switch (S9) needs to be in the OSC
position. However, to use the SMA connectors J5 and J6, the slide switch
needs to be in the SMA position. The I/O standard of the pattern generator
should be set to LVPECL, LVDS, LVHSTL, SSTL, or the HCSL level.
Table 2–2. Setting the Clock Circuit Switches, Note (1)
S8-1, S8-2, and PCIe Clk S8-3, S8-4 and PCIe Clk S8-5 and PCIe Clk S8-6 and Basic Clk
S8-1 S8-2
PCIe Clk
(U5)
S8-3 S8-4
PCIe Clk
(U5)
S8-5
PCIe Clk
(U5)
S8-6
Basic Clk
(U8)
Low Low 25 MHz Low Low ±25% High Enable High Enable
High Low 100 MHz High Low -0.5 % Low Disable Low Disable
Low High 125 MHz Low High -0.75 % — — — —
High Low 200 MHz High High No
spread — — — —
Note to Table 2–2 :
(1) When using the clock speed DIP switch bank (S8), set switches 1-5, 7, and 8 in the closed position, and switch 6 in
the open position.
