Altera RAM-Based Shift Register User Manual
Page 23
Chapter 3: Specifications
3–3
Ports and Parameters for the ALTSHIFT_TAPS Megafunction
May 2013
Altera Corporation
RAM-Based Shift Register (ALTSHIFT_TAPS) Megafunction User Guide
shows the ALTSHIFT_TAPS megafunction parameters.
Table 3–3. Shift Register (RAM-based) MegaWizard Plug_In Parameters
Name
Type
Required
Description
NUMBER_OF_TAPS
Integer
Yes
Specifies the number of regularly spaced taps along the shift register.
TAP_DISTANCE
Integer
Yes
Specifies the distance between the regularly spaced taps in clock cycles.
This number translates to the number of RAM words that will be used.
TAP_DISTANCE
must be at least 3.
WIDTH
Integer
Yes
Specifies the width of the input pattern.
POWER_UP_STATE
String
No
Specifies the shift register contents at power-up. Values are CLEARED and
DONT_CARE
. If omitted, the default is CLEARED.
Value
Description
CLEARED
Zero content. For Stratix and
Stratix II device families, you must
use M512 or M4K RAM blocks.
DONT_CARE
Unknown contents. M-RAM blocks
can be used with this setting.
