Technical details
Operating Manual PSSu K S 16DO 0.5
22059­EN­07 27
8 Technical details
General 312432
Approvals BG, CE, GOST, TÜV, cULus Listed
Application range Standard
Module's device code 0430h
Number of ST output bits 16
Application in system environment A
From ST firmware version, other head modules 17
From ST firmware version PSSu H S PN 2
From ST firmware version PSSu WR S IDN 9
Application in system environment B
From ST firmware version, head modules 1.7.0
Electrical data 312432
Supply voltage
for Outputs
Voltage 24 V
Kind DC
Voltage tolerance ­30 %/+25 %
Max. continuous current that the external power
supply must provide
10,0 A
Internal supply voltage (module supply)
Supply voltage range of module supply 4,8 ­ 5,4 V
Module's current consumption 40 mA
Module's power consumption 0,20 W
Unit fuse protection F1 may in accordance with
UL508
4 A
Permitted loads inductive, capacitive, resistive
Semiconductor outputs 312432
Number of positive­switching single­pole semicon­
ductor outputs
16
Voltage 24 V DC
Typ. output current at "1" signal and rated voltage of
semiconductor output
0,50 A
Permitted current range 0,00 ­ 0,62 A
Residual current at "0" signal 0,02 mA
Max. transient pulsed current 6 A
Max. internal voltage drop 60 mV
Max. processing time of semiconductor output when
signal changes from "1" to "0"
0,500 ms
Max. processing time of semiconductor output when
signal changes from "0" to "1"
0,010 ms
Potential isolation from system voltage Yes
Short circuit­proof Yes
Environmental data 312432
Climatic suitability EN 60068­2­1, EN 60068­2­14, EN 60068­2­2, EN
60068­2­30, EN 60068­2­78
