8-1
8.1 Technical details
8 Technical details
8 8000 Technical details Technical details 8- 8.1 Technical details 8100 Technical details 8- ][Technische Daten PSSu Kopf SBUS
Technical details
Application range Failsafe
Maximum achievable category in accordance with
EN 954-1 4
Maximum achievable SIL value SIL3
Module's device code 0220h
Electrical data
Internal supply voltage
Supply voltage range of module supply
4.9 - 5.1 V
Current and power consumption from module supply
Module's current consumption without FO connection
205 mA
FO connection's current consumption 120 mA
Module's power consumption without FO connection 1.03 W
FO connection's power consumption 0.60 W
Max. power dissipation of the module 1.03 W
Potential isolation between module supply and
SafetyBUS p 700 V
SafetyBUS p
Application range
Failsafe applications
Device address 32d ... 95d
Max. transmission rate 500 kBit/s
Cable runs 3,500 m
Transmission type differential two-wire cable
Connection Male 9-pin D-SUB connector
USB
Connection
Mini-B connector
Environmental data
Climatic suitability
EN 60068-2-14, EN 60068-2-1, EN 60068-2-2,
EN 60068-2-30, EN 60068-2-78
Ambient temperature 0 - 60 °C
-40 - 70 °C coated version (-T)
Storage temperature -25 - 70 °C
-40 - 70 °C coated version (-T)
Climatic suitability in accordance with EN 60068-2-78 93 % r. h. at 40 °C
Condensation no
yes coated version (-T)
Max. operating height above sea level 5000 m coated version (-T)
EMC EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,
EN 61000-4-5, EN 61000-4-6, EN 61000-6-2,
EN 61000-6-4
Vibration to EN 60068-2-6
Frequency
10 - 150 Hz
Max. acceleration 1g
Shock stress
EN 60068-2-27
15g
11 ms
EN 60068-2-29 10g
16 ms
Protection type
Mounting (e.g. cabinet)
IP54
Housing IP20
