7.1 Messages
7 Operation
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
7-2
(
1
) There are two levels of overtemperature.
 Too warm:
If a module's temperature exceeds a theshold value, the module
sends a warning to the head module. If the temperature drops back
below the threshold value, the module sends an all-clear.
 Too hot:
If a module's temperature exceeds a further theshold value, the mod-
ule sends an error message to the head module and triggers an
I/O-Group stop.
Further information on PSSu error messages is available in the online
help for the PSS WIN-PRO system software.
Undervoltage error A system voltage or infeed is too low. Stabilise the supply or change the
faulty supply voltage module.
Error in the overvoltage protection di-
odes Overvoltage protection diodes are de-
fective. Change faulty supply voltage module.
Module error Explanation Remedy
