Technical details
Operating Manual PNOZ m EF 4DI4DOR
1002702­EN­02 17
Environmental data 772143
Protection type
In accordance with the standard EN 60529
Mounting (e.g. cabinet) IP54
Housing IP20
Terminals IP20
Mechanical data 772143
Mounting position Horizontal on top hat rail
Mechanical life 10,000,000 cycles
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Max. cable length
Max. cable length per input 1,0 km
Material
Bottom PC
Front PC
Top PC
Conductor cross section with screw terminals
1 core flexible 0,25 ­ 2,50 mm², 24 ­ 12 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors
0,20 ­ 1,50 mm², 24 ­ 16 AWG
Torque setting with screw terminals 0,50 Nm
Connection type Spring­loaded terminal, screw terminal
Mounting type plug in
Conductor cross section with spring­loaded terminals:
flexible with/without crimp connector
0,20 ­ 2,50 mm², 24 ­ 12 AWG
Spring­loaded terminals: Terminal points per connec­
tion
2
Stripping length 9 mm
Dimensions
Height 101,4 mm
Width 22,5 mm
Depth 120,0 mm
Weight 190 g
The standards current on 2012­04 apply.
