Technical details
Operating Manual PNOZ m EF 1MM
1003108­EN­01 21
8 Technical details
General 772170
Approvals BG, CCC, CE, GOST
Application area Failsafe
Module's device code 00E3h
Electrical data 772170
Supply voltage
For Module supply
Internal Via base unit
Voltage 24,0 V
Type DC
Current consumption 107 mA
Power consumption 2,6 W
Status indicator LED
Proximity switch input 772170
Number of inputs 2
Input signal level
Signal level at "1" 11 ­ 30 V
Signal level at "0" ­3 ­ 5 V
Input resistance 22 kOhm
Input's frequency range 0 ­ 3 kHz
Configurable monitoring frequency
Without hysteresis 0.1 Hz ­ 3 kHz
Times 772170
Reaction time after limit value is exceeded 1/f_ist + 16 ms
Environmental data 772170
Ambient temperature
In accordance with the standard EN 60068­2­14
Temperature range 0 ­ 60 °C
Forced convection in control cabinet off 55 °C
Storage temperature
In accordance with the standard EN 60068­2­1/­2
Temperature range ­25 ­ 70 °C
Climatic suitability
In accordance with the standard EN 60068­2­30, EN 60068­2­78
Condensation during operation Not permitted
EMC EN 61131­2
Vibration
In accordance with the standard EN 60068­2­6
Frequency 5,0 ­ 150,0 Hz
Acceleration 1g
