Technical Details
Operating Manual PNOZ mc12p
1003016-EN-01
17
Environmental data 773719
Rated insulation voltage 25 V
Protection type
In accordance with the standard EN 60529
Mounting (e.g. cabinet) IP54
Housing IP20
Terminals IP20
Potential isolation 773719
Potential isolation between Fieldbus and module voltage
Type of potential isolation Functional insulation
Rated surge voltage 500 V
Mechanical data 773719
Mounting position Horizontal on top hat rail
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Material
Bottom PPO UL 94 V0
Front ABS UL 94 V0
Dimensions
Height 94,0 mm
Width 22,5 mm
Depth 114,0 mm
Weight 115 g
The standards current on 2012-06 apply.
