Technical Details
Operating Manual PNOZ mc7p
1003050-EN-01
15
Technical Details
General 773716
Approvals CCC, CE, GOST, cULus Listed
Electrical data 773716
Supply voltage
For Module supply
Voltage 5,0 V
Type DC
Voltage tolerance -2 %/+2 %
Power consumption 2,5 W
Status indicator LED
Fieldbus interface 773716
Fieldbus interface CC-Link V1.10
Unit type Slave
Station address 0 ... 63d
Transmission rates 10 MBit/s, 156 kbit/s, 2,5 MBit/s, 5 MBit/s, 625
kbit/s
Connection 5-pin Combicon plug-in connector
Assigned stations 2
Galvanic isolation Yes
Test voltage 500 V AC
Times 773716
Supply interruption before de-energisation 20 ms
Environmental data 773716
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range 0 - 60 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-30, EN 60068-2-78
Humidity 93 % r. h. at 40 °C
Condensation Not permitted
EMC EN 61131-2
Vibration
In accordance with the standard EN 60068-2-6
Frequency 10,0 - 150,0 Hz
Acceleration 1g
Shock stress
In accordance with the standard EN 60068-2-27
Acceleration 15g
Duration 11 ms
Max. operating height above sea level 2000 m
