8-1
8.1 Technical details
8 Technical details
8 8000 Technical details Technical details 8- 8.1 Technical details 8100 Technical details 8- ][Technische Daten_multi_Basis
Technical details
Electrical data
Supply voltage U
B
DC 5 V
Power consumption at U
B
DC
without load 3.5 W
Status display LED
Times
Switch-on delay
5.00 s
Supply interruption before de-energisation 20 ms
Relay outputs
Number
4
Utilisation category in accordance with EN 60947-4-1
Safety contacts: AC1 at 240 V
6.0 A, 1440 VA
Safety contacts: DC1 at 24 V 6.0 A, 144 W
Utilisation category in accordance with EN 60947-5-1
Safety contacts: AC15 at 230 V
3.0 A, 690 W
Safety contacts: DC13 at 24 V (6 cycles/min) 3.0 A, 72 W
Derating of coated version at an ambient temperature > 50
°C
Safety contacts: AC1 at 240 V
2 A coated version, 480 W coated version
Safety contacts: DC1 at 24 V 2 A coated version, 48 W coated version
Utilisation category in accordance with EN 60947-5-1
Safety contacts: AC15 at 230 V coated version
2 A coated version, 460 W coated version
Safety contacts: DC13 at 24 V coated version (6 cycles/
min) 2 A coated version, 48 W coated version
Airgap creepage between
relay contacts
3 mm
relay contacts and other safe circuits 5.5 mm
External contact fuse protection (I
K
= 1 kA) to
EN 60947-5-1
Blow-out fuse, quick
6 A
Blow-out fuse, slow 6 A
Circuit breaker 24 VAC/DC, characteristic B/C 6 A
Switch-off delay 50 ms
Environmental data
Climatic suitability
EN 60068-2-1, EN 60068-2-30, EN 60068-2-78
Ambient temperature 0 - 60 °C
-25 - 60 °C coated version
Storage temperature -25 - 70 °C
Climatic suitability 95 % r. F. coated version
Condensation permitted coated version
EMC EN 60947-5-1
Vibration to EN 60068-2-6
Frequency
10 - 55 Hz
Amplitude 0.35 mm
Mechanical data
Protection type
Mounting (e.g. cabinet)
IP54
Housing IP20
Terminals IP20
