iQ Series

,

Ultrasonic Generator/Power Supply LS User’s Manual

Section 4 – Standard Connections

Page  31

Page  30 

 

 

 

 

 

 

 

 

 

iQ Series

,

Ultrasonic Generator/Power Supply LS User’s Manual

Section 4 – Standard Connections

Dukane Manual Part No. 403-574-01

Pin 23

(Suspect Part Status Output)

Pin 23 is a digital active low status output that activates,
either momentarily or until the start of the next welding
cycle, when the welding parameters recorded during the
previous welding cycle are outside of the programmed
suspect part limits. This output will be an open circuit
after a welding cycle when a suspect part has not been
detected.

Pin 24

(Isolated Common)

Pin 24 is electrically isolated from chassis ground. This
common line should be connected to negative output
at a user-provided isolated 24VDC power supply. The
isolated NPN status output signals can drive PNP inputs.

Pin 25

(Not Used)

Pin 25 is an open connection.

Pin

Signal Name

Cable Color Code

Signal Option Requirements

1

+22V

BLK

2

Spare Output

WHT

3

+22V Power Ground

RED

4

Programmable Status Output 1

GRN

5

Programmable Status Output 2

ORN

6

Ultrasound Active Status Output

BLU

7

Any Fault Status Output

WHT/BLK

8

Press Trigger Status Output

RED/BLK

Not Available

9

System Overload Status Output

GRN/BLK

10

System Online Status Output

ORN/BLK

11

Press Top of Stroke Status Output

BLU/BLK

Not Available

12

Current Loop OK Status Output

BLK/WHT

Remote Control Option Board

13

Analog Monitor Signal Common

RED/WHT

14

Not Used

GRN/WHT

15

Power Signal Monitor Output

BLU/WHT

16

Amplitude Monitor Output

BLK/RED

17

Amplitude/Power Regulation Status Output

WHT/RED

18

MPC Ready Status Outputs

ORN/RED

MPC Option Board

19

System Power OK Status Output

BLU/RED

20

Bad Part Status Output

RED/GRN

21

Good Part Status Output

ORN/GRN

22

System Ready Status Output

BLK/WHT/RED

23

Suspect Part Status Output

WHT/BLK/RED

24

Isolated Common

RED/BLK/WHT

25

Not Used

GRN/BLK/WHT

Table 4 - II System Output Connector Signals (J3)
