Figure 4.1 - configuration word, 50 khz counter / flowmeter module – Spectrum Controls 1746sc-CTR4 User Manual
Page 28
28
SLC 500
™
50 KHz Counter / Flowmeter Module
Figure 4.1 - Configuration Word
Channel 1 Rate Limit / R Factor
O:e.7
Channel 1 Limit / K Factor
O:e.6
Channel 1 Preset / M Factor
O:e.5
Channel 1 Configuration Word
O:e.4
Channel 2 Rate Limit / R Factor
O:e.11
Channel 2 Limit / K Factor
O:e.10
Channel 2 Preset / M Factor
O:e.9
Channel 2 Configuration Word
O:e.8
Channel 3 Rate Limit / R Factor
O:e.15
Channel 3 Limit / K Factor
O:e.14
Channel 3 Preset / M Factor
O:e.13
Channel 3 Configuration Word
O:e.12
Channel 4 Rate Limit / R Factor
O:e.19
Channel 4 Limit / K Factor
O:e.18
Channel 4 Preset / M Factor
O:e.17
Channel 4 Configuration Word
O:e.16
Channel 5 Rate Limit / R Factor
O:e.23
Channel 5 Limit / K Factor
O:e.22
Channel 5 Preset / M Factor
O:e.21
Channel 5 Configuration Word
O:e.20
Channel 6 Rate Limit / R Factor
O:e.27
Channel 6 Limit / K Factor
O:e.26
Channel 6 Preset / M Factor
O:e.25
Channel 6 Configuration Word
O:e.24
Channel 7 Rate Limit / R Factor
O:e31
Channel 7 Limit / K Factor
O:e.30
Channel 7 Preset / M Factor
O:e.29
Channel 7 Configuration Word
O:e.28
15
0
Address
Channel 0 Rate Limit / R Factor
O:e.3
Channel 0 Limit / K Factor
O:e.2
Channel 0 Preset / M Factor
O:e.1
Channel 0 Configuration Word
O:e.0
CTR4
CTR8
