Chapter 3: Things To Consider Before Using Your Module 21
Output Image - Configuration Words
Thirty-two (CTR-8) or sixteen (CTR-4) words of the SLC processor’s
output image table are reserved for the module. For the CTR8, output
image words 0-31 are used to configure input channels 0-7. For the
CTR4, output image words 0-15 are used to configure input channels 0-4.
Each output image word configures a single channel, sets the preset, limit
and scale factors and can be referred to as a configuration word. Each
word has a unique address based on the slot number assigned to the
module.
Example Address - If you want to configure channel 2 on the module
located in slot 4 in the SLC chassis, your address would be O:4.4.
O:4.2
File type
Slot
Word
Element
Delimiter
Word
Delimiter
Chapter 4, Channel Configuration, Data, and Status, gives you detailed
bit information about the data content of the configuration word.
Input Image - Data Words and Status Words
Count data, Rate data, and status are given in four input words for each
channel.
Chapter 4, Channel Configuration, Data, and Status, gives you detailed
bit information about the content of the data word and the status word.
