SpectraCal Lumagen Radiance User Manual
SpectraCal Computer Accessories

3528 Bagley Ave. N. Seattle, WA 98103 USA
Corporate: +1 206 420 7514 | Tech Support: +1 206 457 8949 |
Lumagen Radiance XD, XE, XS, Mini 3D,
20xx series, 21xx series
Quick Start Guide
Lumagen Radiance
The Lumagen Radiance™ processors dramatically improve any display’s picture quality, with superior,
industry-leading Radiance processing. They also provide controls to calibrate 11 or 21 point grayscale
and either standard CMS primary and secondary color points, or a 3D cube lookup table (LUT) for
SMPTE video level signals. The Radiance XD, Mini, XE, and XS provide a 125 point 5x5x5 LUT. The
Radiance 20xx series provide a 729 point 9x9x9 LUT. The Radiance 21xx series provide a 4913 point
17x17x17 LUT.
Included Parts
In the Radiance shipping box you will find:
Lumagen Radiance processor
Power supply
Remote control
RS232 serial null-modem 1 meter cable
USB to RS232 serial adapter
Radiance Firmware
Any recent version for grayscale and standard CMS calibration.
Version 091112, or newer, for 3D LUT calibration
Firmware updates can be found at
To update the Lumagen firmware, connect the supplied RS232 (null modem) cable between the RS232
port on the Radiance and your PC, unzip the update file from Lumagen, and run the update program.
Select the appropriate RS232 port, select the 57600 baud rate, and click Start. While the update is being
performed, the Lumagen will display “Update in Progress” on its video output.
Note: For connecting to and controlling a Radiance with computers that do not have an RS232
connection, SpectraCal recommends the FTDI USB to RS232 converter, supplied with the unit. Thorough
