DOLBY PRM-4200
CalMAN Setup Guide
CalMAN Display Calibration Software can automatically create an optimized 3D calibration LUT for the
Dolby PRM-4200 monitor. Follow the procedure below to automatically create and load an optimized 3D
LUT monitor calibration file into one of the Dolby monitor’s Custom operating modes.
Required CalMAN Software Version:
Version 5.4.0 or newer
Required CalMAN Workflow:
Color Cube (3D LUT)
Dolby Monitor Software Version:
3.4.1.1 or newer
Dolby Monitor Control Connection:
Ethernet port on rear of monitor
Dolby Network Connection
Connect the Dolby PRM-4200 to the same network router or local area network as the CalMAN
computer, with an Ethernet cable.
Dolby Initial Setup
To calibrate the Dolby monitor with a 3D LUT, you must manually configure two settings in the
monitor before you connect to the monitor within CalMAN:
1. On the Dolby remote, select either the Custom 1 or the Custom 2 operating mode to enable
3D LUT calibration.
Note: There are no Brightness, Contrast or Luminance controls available in the Custom
operating modes.
2.
On the Dolby remote, press the Edit key to set the Video Range to either ‘SMPTE,’ ‘Full,’ or
‘Custom
.’
To set a SMPTE+ range under Custom (SMPTE black, extended white), set Range
max to 4095 and set Range min to 256.
Note: The Dolby Video Range selection needs to be set before connecting CalMAN to the
Dolby monitor.
