Dimensions – SOR 815DT Smart User Manual
Page 20
20/24
Form 1588 (09.14) ©SOR Inc.
34.1
1.34
146.2
5-3/4
158.9
6-1/4
27.9
1.10
55.9
2.20
ELECTRICAL
CABLE
ELECTRICAL
CONNECTION
1/2 NPTM
28.6
1-1/8 FLATS
ZERO
MAGNETIC
TARGET
SPAN
MAGNETIC
TARGET
MODEL
DP86CV
1/4 NPTF
LO SIDE
PROCESS
CONNECTION
1/4 NPTF
HI SIDE
PROCESS
CONNECTION
EXTERNAL
GROUND
PROVISION
Dimensions
Dimensions are for reference only.
Contact the factory
for certified drawings
for a particular model number.
Linear = mm/inches
Drawing 0091544
