SOR 815DT Smart - Manual (Page 16)

16/24 Form 1588 (09.14) ©SOR Inc.
HART
Command
Description
Command Data Command Reply Data
Byte Description Byte Description
132
Device
configuration
0
"Configuration part type:
3: Switch Output Mode
4: Zero/Span Switches Enabled
5: Loop Type
6: Loop Alarm Direction
7: Fixed Output Duration
8: Fixed Output Span Percentage
13: Switch Point Low
14: Switch Point High
15: PWM Frequency Minimum
16: PWM Frequency Maximum
17: PWM Duty Cycle Minimum
18: PWM Duty Cycle Maximum
19: Modbus Slave ID
20: Modbus Parity
21: Modbus Baud Rate
24: Current Loop Trim Offset
25: Current Loop Trim Gain
26: Voltage Loop Trim Offset
27: Voltage Loop Trim Gain"
Write only
1 Always 1
"Parts 3-6,
19-20:
2
Parts 7, 15-
16, 24-25:
2-3
Parts 8, 13-
14, 17-18,
21, 26-27:
2-5"
Configuration part value
133 0
"Configuration part type:
3: Switch Output Mode
4: Zero/Span Switches Enabled
5: Loop Type
6: Loop Alarm Direction
7: Fixed Output Duration
8: Fixed Output Span Percentage
13: Switch Point Low
14: Switch Point High
15: PWM Frequency Minimum
16: PWM Frequency Maximum
17: PWM Duty Cycle Minimum
18: PWM Duty Cycle Maximum
19: Modbus Slave ID
20: Modbus Parity
21: Modbus Baud Rate
24: Current Loop Trim Offset
25: Current Loop Trim Gain
26: Voltage Loop Trim Offset
27: Voltage Loop Trim Gain"
"Parts
3-6,
19-20:
0
Parts 7,
15-16,
24-25:
0-1
Parts 8,
13-14,
17-18,
21, 26-
27:
0-3"
Configuration
part value
