HART
Command
Description
Command Data Command Reply Data
Byte Description Byte Description
9
(cont)
Read device
variables with
status
6
Device variable
code slot 6
9 Slot 1: Device variable class
7
Device variable
code slot 7
10 Slot 1: Units code
11-14 Slot 1: Device variable value
15 Slot 1: Device variable status
16 Slot 2: Device variable code
17 Slot 2: Device variable class
18 Slot 2: Units code
19-22 Slot 2: Device variable value
23 Slot 2: Device variable status
24 Slot 3: Device variable code
25 Slot 3: Device variable class
26 Slot 3: Units code
27-30 Slot 3: Device variable value
31 Slot 3: Device variable status
32 Slot 4: Device variable code
33 Slot 4: Device variable class
34 Slot 4: Units code
35-38 Slot 4: Device variable value
39 Slot 4: Device variable status
40 Slot 5: Device variable code
41 Slot 5: Device variable class
42 Slot 5: Units code
43-46 Slot 5: Device variable value
47 Slot 5: Device variable status
48 Slot 6: Device variable code
49 Slot 6: Device variable class
50 Slot 6: Units code
51-54 Slot 6: Device variable value
55 Slot 6: Device variable status
56 Slot 7: Device variable code
57 Slot 7: Device variable class
58 Slot 7: Units code
59-62 Slot 7: Device variable value
63 Slot 7: Device variable status
64-67 Timestamp
