16
PALSUN® Recommended Panel Width for Curved Installation - Metric
Maximum Recommended on Center Distance between Supporting Arches
Thickness
Sheet Curvature
Radius
Maximum Recommended on Center Distance between Supporting Arches
According to Wind/Snow Loads Below (mm)
Uniform Wind/Snow Loads (kg/m2)
50 80 100 120 150 200 250 300
4mm
700 2050 2050 2050 2050 2050 1900 1750 1600
900 2050 2050 1850 1650 1500 1350 1200 1000
1100 2050 1900 1750 1600 1450 1250 1050 900
1300 1950 1800 1650 1480 1320 1180 1000 820
1500 1800 1650 1500 1380 1200 1050 900 750
1800 1650 1580 1420 1320 1120 950 820 700
2000 1580 1480 1350 1250 1050 880 750 650
2200 1500 1400 1300 1180 980 800 680 600
2800 1350 1250 1180 1100 900 720 600 NA
4000 1200 1050 950 850 780 650 450 NA
6000 850 780 720 650 600 450 NA NA
5mm
900 2050 2050 2050 2050 2050 2050 1900 1750
1100 2050 2050 2050 2050 2050 1900 1750 1600
1300 2050 2050 2050 2050 1950 1750 1600 1450
1500 2050 2050 2050 1950 1850 1700 1550 1400
1800 2050 2050 1950 1850 1750 1550 1350 1150
2000 2050 1950 1850 1750 1550 1350 1150 1050
2200 1950 1850 1750 1650 1500 1300 1100 1000
2800 1600 1500 1400 1300 1200 1050 900 750
4000 1400 1300 1200 1100 1000 850 750 600
6000 1200 1050 950 850 750 600 450 NA
6mm
1100 2050 2050 2050 2050 2050 2000 1900 1750
1300 2050 2050 2050 2050 2050 1900 1750 1600
1500 2050 2050 2050 2050 1900 1750 1600 1450
1800 2050 2050 2050 1950 1800 1650 1500 1350
2000 2050 2050 1950 1850 1700 1550 1400 1250
2200 2050 1950 1850 1750 1650 1500 1350 1200
2800 1700 1600 1500 1400 1300 1150 1000 850
4000 1600 1500 1400 1300 1150 1000 850 720
6000 1480 1380 1300 1200 1080 920 780 620
8mm
1500 2050 2050 2050 2050 2050 1900 1750 1600
1800 2050 2050 2050 2050 1950 1800 1650 1500
2000 2050 2050 2050 2000 1900 1750 1600 1450
2200 2050 2050 2050 1950 1850 1700 1550 1400
2500 2050 2050 1920 1850 1720 1580 1420 1280
2800 2050 1950 1820 1720 1600 1450 1300 1150
4000 1950 1820 1720 1620 1500 1350 1200 1000
6000 1820 1680 1520 1380 1250 1100 950 780
10mm
1800 2050 2050 2050 2050 2050 1950 1800 1650
2200 2050 2050 2050 2050 2000 1850 1700 1550
2800 2050 2050 2050 1950 1800 1750 1600 1450
4000 2050 2050 2000 1900 1780 1620 1480 1320
6000 2050 1920 1820 1720 1550 1400 1250 1100
12mm
2200 2050 2050 2050 2050 2050 2050 1950 1800
2800 2050 2050 2050 2050 2050 1950 1800 1650
4000 2050 2050 2050 2050 1950 1800 1650 1480
6000 2050 2050 2050 1950 1720 1580 1420 1280
* See notes on next page
