Specifications
Voltage Class
115V Class
Model Number VFD-XXXM
002
004
007
Max. Applicable Motor Output (kW)
0.2
0.4
0.75
Max. Applicable Motor Output (hp)
0.25
0.5
1.0
Rated Output Capacity (kVA)
0.6
1.0
1.6
Rated Output Current (A)
1.6
2.5
4.2
Maximum Output Voltage (V)
3-Phase proportion to twice the input voltage
Output Frequency (Hz)
0.1~400 Hz
Outp
ut Rati
ng
Carrier Frequency (kHz)
1-15
Single phase
Rated Input Current (A)
6 9 16
Rated Voltage, Frequency
Single phase, 100-120 VAC, 50/60Hz
Voltage Tolerance
+-10% (90-132VAC)
Inpu
t Ratin
g
Frequency Tolerance
±
5% (47~63Hz)
Cooling Method
Fan Cooled
Weight (kg)
1.5
1.5
1.5
Voltage Class
230V Class
Model
Number
VFD-XXXM
004 007 015 022 037 055
Max. Applicable Motor Output (kW)
0.4
0.75
1.5
2.2
3.7
5.5
Max.
Applicable
Motor
Output
(hp)
0.5 1.0 2.0 3.0 5.0 7.5
Rated
Output
Capacity
(kVA)
1.0 1.9 2.7 3.8 6.5 9.5
Rated Output Current (A)
2.5
5.0
7.0
10
17
25
Maximum Output Voltage (V)
3-Phase proportional to input voltage
Output Frequency (Hz)
0.1~400 Hz
Outp
ut Rati
ng
Carrier Frequency (kHz)
1-15
Single/3-phase 3-phase
Rated Input Current (A)
6.3/2.9
11.5/7.6 15.7/8.8 27/12.5 19.6
28
Input Current for 1-phase
Models when Using 3-phase
Power
3.2 6.3 9.0 12.5 -- --
Rated Voltage, Frequency
Single/3-phase
200-240 VAC, 50/60Hz
3-phase
200-240VAC, 50/60Hz
Voltage Tolerance
+-10% (180~264 VAC)
Inpu
t Ratin
g
Frequency Tolerance
±
5% (47~63 Hz)
Cooling Method
Fan Cooled
Weight (kg)
2.2/1.5
2.2/1.5
2.2/1.5
3.2/2.2
3.2
3.2
Voltage Class
460V Class
Model
Number
VFD-XXXM
007 015 022 037 055 075
Max. Applicable Motor Output (kW)
0.75
1.5
2.2
3.7
5.5
7.5
Max. Applicable Motor Output (hp)
1.0
2.0
3.0
5.0
7.5
10
Rated Output Capacity (kVA)
2.3
3.1
3.8
6.2
9.9
13.7
Rated
Output
Current
(A) 3.0 4.0 5.0 8.2 13 18
Maximum Output Voltage (V)
3-phase Proportional to Input Voltage
Output Frequency (Hz)
0.1~400 Hz
Outp
ut Rati
ng
Carrier Frequency (kHz)
1-15
3-phase
Rated Input Current (A)
4.2 5.7 6.0 8.5 14 23
Rated Voltage, Frequency
3-phase 380~480 VAC, 50/60Hz
Voltage Tolerance
+-10% (342~528 VAC)
Inpu
t Ratin
g
Frequency Tolerance
±
5% (47~63 Hz)
Cooling Method
Fan Cooled
Weight
(kg)
1.5 1.5 2.0 3.2 3.2 3.3
