8
IntelliDrive Controller software
and network configuration
Software and App Downloads and Installation
For download of the IntelliDrive Controller software for Mac and
PC, please visit www.ipdseries.com. Instructions for installation are
available via this link.
The IntelliDrive Controller app for iPad Is available from Apple in the
App Store.
Network configuration
A network of IPD amplifiers may be configured using standard,
off-the-shelf Ethernet router and Cat-5 cabling. If the router is
WiFi enabled, the IPD amplifier network will be accessible using an
iPad or laptop computer running IntelliDrive Controller software.
The IPD network employs a star topology only. Each amplifier must be
connected individually to the router.
Wireless Router
Cat-5e
iPad / Tablet
iPad
PC or Mac Computer
Cat-5e
(direct connection may require
crossed cable or MDI/X capable NIC)
Network Router
Cat-5e PC / Mac
PC / Mac
Network configuration is automatic. Each amplifier is identified by a
unique IP address, which is shown in the Global view and the device
header panel of IntelliDrive Controller.
For more detailed information on network configuration, please refer to
the IPD Series Operation Manual.
Input mixing/routing and DSP configuration using
IntelliDrive Controller
All input mixing /routing functions and DSP configuration parameters
are accessible and adjustable using IntelliDrive Controller software. The
device header panel appears at the top of each configuration window
for a selected device. For more detailed information on mixing/routing
and DSP adjustment, please refer to the IPD Series Operation Manual.
