X1 MF

Batteries installed in a device or which are electrically linked to
other components
Batteries that are not expressly stated by the manufacturer to
be suitable for the currents the charger delivers during the
charge process

Did you select the appropriate program suitable for the type of
battery you are charging?
Did you set up adequate current for charging or discharging?
Have you checked the battery voltage? Lithium battery packs
can be wired in parallel and in series, i.e. a 2-cell pack can be
3.7V (in parallel) or 7.4V (in series).
Have you checked that all connections are firm and secure?
Make sure there are no intermittent contacts at any point in the
circuit.

3.7V/cell

4.2V/cell

3.8V/cell

̰1C

3.0-3.3V/cell

3.6V/cell

4.1V/cell

̰1C

3.3V/cell

3.6V/cell

3.3V/cell

̰4C

1.2V/cell

1.5V/cell

n/a

1C-2C

1.2V/cell

1.5V/cell

n/a

1C-2C

2.0V/cell

2.46V/cell

n/a

̰0.4C

2.9-3.2V/cell 2.6-2.9V/cell 0.1-1.1V/cell 0.1-1.1V/cell

1.8V/cell

Please bear in mind the following points before commencing
charging:

Standard Battery Parameters

CAUTION! When adjusting your X1 MF charging parameters, be sure you select the
proper battery type and cell voltage for the type of cell you are charging. Charging
batteries with the wrong settings may cause the cells to burst, catch fire, or explode.
