22
X1 MF
- + - +
Elapsed
time Discharged
or charged
capacity
> 3 seconds
Mode
Stop
SELECT SELECT
Elapsed
time Discharged
capacity
Press
Dial
NiMH 0.1A 7.42V
DSC 022:45 00919
NIMH CYCLE
CHG > DCHG 1
NiMH 1.0A 7.42V
C>D 022:19 00919
This screen displays the real-time status of
the discharge process. Pressing the
Mode/Stop button once will end the
discharge process and return you to the
setup screen.
You can adjust the cycle flow
(Discharge>Charge or Charge>Discharge)
from this screen as well as the number of
cycles requested. Pressing the dial for 3
seconds will start the process.
From this screen you can press the dial once
and scroll to adjust the current, or press the
Mode/Stop button once to end the process
and return to the setup screen.
Battery
type Battery
voltage Discharge
current
Battery
type Battery
voltage Discharge
Charge or
current
