A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS
a
Switch
1 x 2, 1 x 4
1 x 8
1 x 12
1 x 16
1 x 24, 1 x 32
Operating wavelength (nm)
1290 to 1650
Insertion loss (dB) at 1310 nm
b, c
0.9
1.2
1.6
1.8
2.0
Insertion loss (dB) at 1530 nm to 1650 nm
b, c
0.7
1.0
1.2
1.4
1.5
Repeatability (dB)
d
0.02
Backreflection (dB)
(typical)
–50 (–55)
Crosstalk (dB) (typical)
50 (60)
Polarization-dependent loss (dB) (typical)
e
0.09 (0.06)
0.11 (0.08)
Switching time (ms)
c
20
30
Fiber type
Singlemode 9/125 μm
Input power (damage threshold) (dBm)
27
Notes
a.
Specifications valid at 23 °C ± 5 °C.
b. Insertion losss per module, including one connector.
c. Typical specifications.
d. Repeatability values are for 100 cycles per switch module at constant temperature with stabilized source/meter.
e. At 1550 nm.
f. 1 x 12 switches with EUI connectors use three slots.
GENERAL SPECIFICATIONS
Switch
1 x 2, 1 x 4
1 x 8
1 x 12
1 x 16
1 x 24, 1 x 32
Number of slots
1
2
2
f
3
5
Dimensions Width
Height
Depth
3.6 cm (1
7
⁄
16
in)
12.5 cm (4
15
⁄
16
in)
28.2 cm (11
1
⁄
8
in)
7.4 cm (2
15
⁄
16
in)
12.5 cm (4
15
⁄
16
in)
28.2 cm (11
1
⁄
8
in)
7.4 cm (2
15
⁄
16
in)
12.5 cm (4
15
⁄
16
in)
28.2 cm (11
1
⁄
8
in)
11.2 cm (4
7
⁄
16
in)
12.5 cm (4
15
⁄
16
in)
28.2 cm (11
1
⁄
8
in)
18.8 cm (7
7
⁄
16
in)
12.5 cm (4
15
⁄
16
in)
28.2 cm (11
1
⁄
8
in)
Weight
0.8 kg (1.1 lb)
0.8 kg (1.8 lb)
1.1 kg (2.2 lb)
1.1 kg (2.2 lb)
1.8 kg (3.9 lb)
Switch life
1 billion (10
9
) cycles minimum
Temperature operating
storage
0 °C to 40 °C (32 °F to 104 °F)
—40 °C to 70 °C (—40 °F to 158 °F)
Maximum relative humidity
80 % non-condensing at 40 °C
Instrument Drivers
LabVIEW™ drivers, SCPI commands and COM/DCOM libraries.
Remote Control
With IQS-600: GPIB (IEEE-488.1, IEEE-488.2) Ethernet and RS-232.
Standard Accessories
User guide, certificate of compliance and calibration certificate.
