Introducing the IQS-9100/9100B Optical Switch
14
IQS-9100/9100B
Typical Applications
3. Using the same test jumpers, connect the light source to one of the
IQS-9100/9100B Optical Switch ports, and connect the switch common
port to the power meter detector port (the IQS-9100/9100B Optical
Switch now replaces the bulkhead connector).
4. The IL registered on the power meter will then be the IQS-9100/9100B
Optical Switch port IL including connectors.
Light Source
IQS-2100
ACTIVE
Power Meter
IQS-1100
1 x 4
IQS-9100
Optical Switch
