Creating customized switch configurations, 15 typical applications – EXFO IQS-9100B Optical Switch for IQS-500/600 User Manual
Page 21
Introducing the IQS-9100/9100B Optical Switch
Optical Switch
15
Typical Applications
Creating Customized Switch Configurations
By interconnecting two or more switch modules, customized switch
configurations can be built. For example, 1 2 and 1 16 switches can be
connected to create a 2 16 switch configuration. To do so, simply connect
the common ports of both switches.
1 x 2
IQS-9100
Optical Switch
IQS-9100
1 x 16 Optical Switch
