Operating the Optical Switch
Optical Switch 31
Optimizing the Application for Repeatability
Optimizing the Application for Repeatability
The optimization for repeatability ensures better accuracy in positioning
the light path when switching.

With optimization activated, every time a switching occurs, the switch
mechanism returns to the “no continuity” (Off) position before
aligning to a new channel position. This option provides better
precision, but with slower switching.

With optimization deactivated, the switch mechanism goes directly to
the new channel position. This option provides faster switching, but
with less precision.
Note: This option is NOT available in the 1 x 2, 2 x 2 and 2 x 4 models.
To optimize switching for repeatability:
1. In the main window, select the Settings function tab.
2. Click the Optimize for Repeatability button. The light indicator on the
button will turn bright green to indicate optimization is active.
