Controlling Multiple Optical Switch Modules
42 IQS-9100/9100B
Setting Parameters for Multiple Modules
To set parameters for all selected modules:
1. Select the Instruments function tab.
2. Make sure that the check box corresponding to each module to
configure is selected.
Information
on selected
modules
Control
Center
Module
selection box
Module status
indicator
Module status Module location information
