FTB-500
49
4
Setting Up Your FTB-500
Positioning Your Unit
You can change the orientation of your unit with the bottom or back
supports.
To position the unit using the supports:
Pull out the support pair that will provide you with the best viewing angle
according to your situation.
I
MPORTANT
The supports should always be used in order to ensure that the unit
is stable during your tests and will not fall down to cause damage
to the test components or injure you.
Four-slot model
There are two sets of stands on
the back of the unit with different
lengths. Select the one that
provides you with the best angle.
Back
support
Bottom support
Eight-slot model
