Using FTB Products in an Automated Test Environment
FTB-500 215
Managing the States of Your FTB-500
The following diagram shows the possible transitions between the
different states.
Note: See the appendix on COM properties and events for more information.
Note: You can also return to local state by turning the device off and on again.
However, this operation will cause the controller to lose control of the
system (no more local lockout state). All settings made on the device by the
controller will be lost (reset of device configuration when turning on).
No. Possible in ActiveX by setting:
1 The RemoteState property to True.
2 The LockoutState property to True.
3 The RemoteState property to False.
4 The LockoutState property to True.
5 The LockoutState property to False.
6 The RemoteState property to True.
7 -----
8 The RemoteState property to False.
9 The LockoutState property to False.
Local
Local Lockout Remote Lockout
Remote
3
5 2
9
6
8
1
7
4
