Eurocom M5 Pro - Manual (Page 75)

Storage Devices, Mouse, & Audio
Audio Features 2 - 5
2
Setup for Audio Recording
To record audio sources on your computer at optimum quality follow the instruc-
tions below:
1. Click Control Panel and make sure you are in Classic View.
2. Click Realtek HD Audio Manager (or right-click the notification area icon and
select Sound Manager).
3. Click Microphone Effects (tab) in Microphone (tab), and then click to select
Noise Suppression
(button), or adjust the Recording Volume level to around 60,
to obtain the optimum recording quality.
4. Click OK to close the control panel and save the settings.

Headphone
Configuration
It is recommended that
you set the Speaker
Configuration
to Ste-
reo when listening
through headphones in
order to maximize audio
quality.
When headphones are
plugged-in you should
select Front Speaker
Out
from the pop-up
(The Current Connected
Device is:
) menu.
Figure 2 - 3
Realtek Audio
Manager -
Recording Setup
