Modules
6 - 6 Setting Up SATA RAID or AHCI Mode
6
13. Go to RAID Level: and press .
14. Choose the RAID Level required (see
Table 6 - 1, on page 6 - 3
for details) and
press .
• RAID0 (Stripe)
• RAID1 (Mirror)
• Recovery
15. Go to any of the disks listed under Select Disks: and select a disk name and
press .
16. Move the cursor down (use the arrow keys) onto to X (o select the disk required
and press .
• If you have selected a Recovery level RAID then you need to select one disk to
be Master disk (M) and one disk to be the Recovery disk (R)
Figure 6 - 3
Select Disks
(Advanced > Intel(R)
Rapid Storage
Technology)
For Recovery
For Stripe or Mirror
