Eurocom M5 Pro User Manual
Page 191
Modules
Sound Blaster Audio 6 - 57
6
Testing 5.1 Surround Sound (Advanced Settings)
If you are using the Sound Blaster X-Fi 3 control panel (Advanced Settings) to test
your headphones/speakers, set up as a 5.1 surround sound system with the micro-
phone jack enabled as the "Center/Subwoofer" (see
) in the Re-
altek HD Audio Manager, you may not hear the low Subwoofer test tone as some
headphones/speakers do not support low frequencies.
If your headphones/speakers do not support low frequencies then follow the instruc-
tions below to obtain an effective sound test.
1. Attach your headphones/speakers to the headphone out jack.
2. Run the Sound Blaster X-Fi 3 control panel from the notification area of the
taskbar (or from the item in the Start screen).
3. Click Advanced Settings (see
Figure 6 - 46 on page 6 - 54
).
4. Select 5.1 Surround under Speaker/Headphones Configuration.
5. Click to place a check in the BASS REDIRECTION check box.
6. Click to place a check in the SUBWOOFER GAIN check box.
7. Move the slider for CROSSOVER FREQUENCY to its maximum setting.
8. Click TEST to hear the sound.
9. Your headphones/speakers will now be configured for 5.1 Surround.
Figure 6 - 48
Bass Management
Sound Blaster X-Fi 3
Advanced Settings
