Eurocom Shark 3 - Manual (Page 36)

30
English
Mini Card Slots
Models A & C:
Slot 1 for WLAN Module or WLAN and
Bluetooth Combo Module
(Factory Option) Slot 2 for 3G Module or
mSATA SSD
Model B:
Slot 1 for WLAN Module or WLAN and
Bluetooth Combo Module
(Factory Option) Slot 2 for mSATA SSD
Environmental Spec
Temperature
Operating: 5 ° C - 35 ° C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 6.15A (120W)
8 Cell Smart Lithium-Ion Battery Pack,
76.96WH
Dimensions & Weight
Model A:
374mm (w) * 250mm (d) * 16.3 - 42.7mm (h)
2.7kg with ODD & 76.96WH Battery
Model B:
413mm (w) * 277.5mm (d) * 17.5 - 44mm (h)
3.2kg with ODD & 76.96WH Battery
Model C:
374mm (w) * 250mm (d) * 16.7 - 43.1mm (h)
2.7kg with ODD & 76.96WH Battery
