21. If you have selected RAID0 (Stripe) then you can adjust the
“Strip Size” to your requirements.
22. If you have selected Recovery then you can adjust the
Synchronization to “On Request” or “Continuous”.
23. Go to Create Volume and press .
24. The RAID volume will then be created and the RAID information
will be displayed under Intel(R) Rapid Storage Technology (in
the Advanced menu).
Figure 4 - RAID Information (Advanced > Intel(R) Rapid
Storage Technology)
25. Press to exit the menu.
26. Press and to “Save Changes and Reset”,
however ensure that the two conditions in the bulleted
points below are met before doing so.
• Make sure the Windows 8.1 OS DVD is in the DVD drive and
as the computer starts up it will automatically boot from the
Windows 8.1 OS DVD (you will be prompted to press a key
to boot from the DVD).
• Make sure your USB flash drive or external USB hard disk is
attached to one of the USB ports on the computer.
27. Press as the computer starts up to bring up the boot
device menu.
28. Select the DVD drive containing the Windows 8.1 OS DVD and
press .
29. Press a key at system startup to begin installing Windows from
your Microsoft Windows 8.1 disc.
30. Click Next > Install Now to continue installing the operating
system as normal (see your Windows documentation if you
need help on installing the Windows OS).
31. A prompt will appear to ask you to Load Driver.
32. Click Browse and browse to the location you copied the files to
on your USB flash drive or external USB hard disk (X: denotes
your USB flash drive or external USB hard disk):
• X:\f6flpy-x64 (Windows 8.1 64bit)
33. Click Next.
34. Follow the on-screen instructions to install the Windows 8.1
operating system.
35. Install the Windows drivers. Make sure you install the Intel
Rapid Storage Technology (IRST) driver.
