System Map: Front View with LCD Panel Open (Model B)
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines.
Figure 6
Front View with LCD
Panel Open (Model B)
1. PC Camera
2. *PC Camera LED
*When the PC camera
is in use, the LED will
be illuminated in red.
3. LCD
4. Power Button
5. Control Center Button
6. Speakers
7. LED Indicators
8. Hot Key Buttons
9. Keyboard
10. Microphone
11. Touchpad & Buttons
11
3
5
1
8
4 6
9
11
7
6
2
10

Wireless Device
Operation Aboard
Aircraft
The use of any por-
table electronic
transmission devic-
es aboard aircraft is
usually prohibited.
Make sure the
WLAN & Bluetooth
module(s) are OFF
if you are using the
computer aboard
aircraft by putting
the system in to Air-
plane Mode.
17.3” (43.94cm)
