Saw controls, Rt45 operator’s manual – Ditch Witch RT45 User Manual
Page 45
Controls - 46
RT45 Operator’s Manual
Right Fender
CMW
®
Saw Controls
1.
Saw swing control
2.
Saw lift control
3.
Backfill blade tilt/saw swing selector
Item
Description
Notes
1.
Saw swing control
To swing saw to left, pull.
To swing saw to right, push.
Note: Control configuration with rear steer option is shown in main
illustration. Control configuration without rear steer is shown in balloon.
