Command Descriptions
2-52
Parameter(s)
< Table 5-1-1 > Set USB COM Parameter(s) Field
Parameter / PID / Size Options Descriptions
STX/ETX Transmission
PID : 00h 00h
Size : 00h 01h (1 Byte)
- 00h
- 01h
Disable *
Enable
Handshaking Protocol
PID : 00h 01h
Size : 00h 03h (3 Bytes)
1
st
~3
rd
Byte
- 00h 00h 00h
- 00h 00h 01h
- 00h 01h 00h
None *
ACK/NAK
Xon/Xoff
Baud Rate
PID : 00h 02h
Size : 00h 01h (1 Byte)
- 02h
- 03h
- 04h
- 05h
- 06h
- 07h
- 08h
- 09h
1200 BPS
2400 BPS
4800 BPS
9600 BPS *
19200 BPS
38400 BPS
57600 BPS
115200 BPS
Data Frame
(Data Bit, Parity, Stop Bit )
PID : 00 03
Size : 00h 01h (1 Byte)
- 02h
- 05h
- 08h
- 09h
- 0Ah
- 0Bh
8, None, 1 *
8, Even, 1
8, Odd, 1
8, None, 2
8, Space, 1
8, Mark, 1
Serial Response Time-out
PID : 00h 04h
Size : 00h 01h (1 Byte)
- 01h
- 04h
- 09h
- 0Fh
- 12h
- 24h
- 4Fh
- 50h
- 48h
- 56h
- 5Ah
- 61h
None
200 ms
500 ms *
800 ms
1 s
2 s
3 s
4 s
5 s
8 s
10 s
15 s
ACK/NAK Retry Count
PID : 00h 05h
Size : 00h 01h (1 Byte)
- 03h
- XXh
3 times *
(See Note)
User-defined: XXh =desired seconds(h)
ACK/NAK Indication
PID : 00h 06h
Size : 00h 01h (1 Byte)
Bit 0
- 0
- 1
Bit 1 ~ 7
ACK/NAK Transmission Fail Indication
Disable
Enable *
Reserved (Always 0)
.
Notes
ACK/NAK Retry Count ranges from 00h (never retry) to FFh (always retry).
