Command Descriptions
2-32
TS A Operation Mode
(TS)
Descriptions
Select operation mode for Tethered A Series Scanner
TS A Operation Mode is equivalent to the Operation Mode Selection in the Set TS Operation
command. It is of more convenience to use TS A Operation Mode of the Action Command Category.
Available for A series
Packet Format
Prefix Opcode Status Length Parameter(s) LRC Suffix
7Eh 80h 08h 05h 00h 00h 03h See Below Variable 7Eh
1 Byte 3 Bytes 1 Byte 2 Bytes 3 Bytes 1 Byte 1 Byte
. Host Requirements
If the device successfully received the above command issued by the host, a “Device ACK” will be sent
to the host right after the device performed the action. Otherwise, a “Device NAK” will be sent to host to
issue a command error. However, if the host can not receive any response from the device within the
user preset time-out duration, please resend the above command.
. Length
Total size (bytes) of the Parameter(s) field
. LRC
”Opcode” XOR “Status” XOR “Length” XOR “Parameter(s)”
Parameter(s)
< Table 4-6 > TS A Operation Mode Parameter(s) Field
Parameter / PID / Size Options Descriptions
TS A Operation Mode
PID :
Size : 00h 03h (3 Byte)
- 00h 01h 01h
- 01h 01h 01h
- 02h 01h 01h
- 04h 01h 00h
- 05h 01h 01h
- 06h 01h 00h
- 07h 01h 00h
- 09h 01h 01h
- 0Dh 01h 01h
Trigger mode *
Force mode
Presentation mode
Level mode
Diagnostic mode
Alternative mode
Toggle mode
Low Power mode
Multiple mode
