Command Descriptions
2-19
Serial Trigger
(ALL)
Descriptions
Start or Stop a scan session
When triggered on, the scanner attempts to obtain the requested data. When triggered off, the
scanner aborts a decode attempt.
Packet Format
Prefix Opcode Status Length Parameter(s) LRC Suffix
7Eh 80h 02h 00h 00h 00h 01h See Variable 7Eh 1 Byte 3 Bytes 1 Byte 2 Bytes 1 Byte 1 Byte 1 Byte . Host Requirements If the device successfully received the above command issued by the host, a “Device ACK” will be sent to the host right after the device performed the action. Otherwise, a “Device NAK” will be sent to host to issue a command error. However, if the host can not receive any response from the device within the user preset time-out duration, please resend the above command.
. Length Total size (bytes) of the Parameter(s) field . LRC ”Opcode” XOR “Status” XOR “Length” XOR “Parameter(s)” Parameter(s) < Table 1-2 > Serial Trigger Parameter(s) Field Parameter / PID / Size Options Descriptions Serial Trigger PID : Size : 00h 01h (1 Byte)
- 00h
- 01h
OFF
ON Pages: 1 … 32 33 34 35 36 … 251 wrong Brand wrong Model non readable This manual is related to the following products: FM480 PL680BT HC PF680BT HC PA670BT HC PL680BT PF680BT PA670BT L780WD L780BT HC L780BT L680BT F790WD F780WD F790BT F780BT F680BT A770BT HC A770BT A770 HC A770 L780 L680 F790 F780 HC F780 F680 F560 See also other documents in the category Cino Scanners: F560 (16 pages) F560 (93 pages) A770BT (4 pages) F780WD (16 pages) F780WD (17 pages) FM480 (16 pages) FM480 (92 pages) A770BT (16 pages) A770BT (113 pages) A770BT (9 pages) A770BT (12 pages) F680BT (16 pages) F680BT (87 pages) F680BT (8 pages) PA670BT (16 pages) Sitemap Variable 7Eh
1 Byte 3 Bytes 1 Byte 2 Bytes 1 Byte 1 Byte 1 Byte
. Host Requirements
If the device successfully received the above command issued by the host, a “Device ACK” will be sent
to the host right after the device performed the action. Otherwise, a “Device NAK” will be sent to host to
issue a command error. However, if the host can not receive any response from the device within the
user preset time-out duration, please resend the above command.
. Length
Total size (bytes) of the Parameter(s) field
. LRC
”Opcode” XOR “Status” XOR “Length” XOR “Parameter(s)”
Parameter(s)
< Table 1-2 > Serial Trigger Parameter(s) Field
Parameter / PID / Size Options Descriptions
Serial Trigger
PID :
Size : 00h 01h (1 Byte)
- 00h
- 01h
OFF
ON
