Command Descriptions
2-31
TS Operation Mode
(TS)
Descriptions
Select operation mode for Tethered Scanner
TS Operation Mode is equivalent to the Operation Mode Selection in the Set TS Operation
command. It is of more convenience to use TS Operation Mode of the Action Command Category.
Available for F & L series
Packet Format
Prefix Opcode Status Length Parameter(s) LRC Suffix
7Eh 80h 08h 00h 00h 00h 01h See Below Variable 7Eh
1 Byte 3 Bytes 1 Byte 2 Bytes 1 Byte 1 Byte 1 Byte
. Host Requirements
If the device successfully received the above command issued by the host, a “Device ACK” will be sent
to the host right after the device performed the action. Otherwise, a “Device NAK” will be sent to host to
issue a command error. However, if the host can not receive any response from the device within the
user preset time-out duration, please resend the above command.
. Length
Total size (bytes) of the Parameter(s) field
. LRC
”Opcode” XOR “Status” XOR “Length” XOR “Parameter(s)”
Parameter(s)
< Table 4-5 > TS Operation Mode Parameter(s) Field
Parameter / PID / Size Options Descriptions
TS Operation Mode
PID :
Size : 00h 01h (1 Byte)
- 00h
- 01h
- 02h
- 04h
- 05h
- 06h
- 07h
- 08h
- 09h
Trigger mode (External triggering) *
Force mode (Continued power on)
Presentation mode (Auto detection)
Level mode (Auto power off)
Diagnostic mode (Test reading)
Alternative mode (Periodic power off)
Toggle mode (Repeat reading)
Flash mode (Pulse driven reading)
Low Power mode (Low Power triggering)
