www.austin-hughes.com UM-X-600-ISM-Q214V2 P.26
Smoke Sensor
Part no. IG-S01-1M
Sensitivity Smoke sensitivity 0.15 ~ 0.3 dB/m
Alarm Output Solid State Relay 24VDC@1A
Alarm LED Red
Audio Alarm 80 dB
Audio Alarm Pattern Continuous beeps
Power Requirement Voltage 12VDC, powered by sensor port
Current Consumption 200uA
Power ON LED Red LED fl ashes every 6 seconds
Housing Chassis & Cover ABS plastic
Color Ivory White
Connection Cable Length 1m / 3m ( option )
Environmental Operating -5 to 50°C Degree
Storage -10 to 60°C Degree
Humidity 5~90%, non-condensing
Dimensions Product 103L x 103W x 55H mm
Weight Net 165g
Supply includes 1 Smoke Sensor with 1m cable
Compatibility: InfraSolution X-2000 series
InfraGuard EC-300M & EC-300
Safety Regulatory FCC & CE certifi ed
Environmental RoHS2 & REACH compliant by SGS
< 4.2 > Smoke Sensor
Smoke sensor comes with a RED LED. When smoke alarm triggers, the RED LED lights on with beep sound continuously.
