20
that specific manufacturer and follow all the chimney manufacturer’s installation requirements. ALWAYS follow a
specific chimney manufacturer’s installation instructions to exacting detail regardless of information provided from other
sources. If there is any discrepancy that requires clarification, please contact Country Flame or a local dealer for
assistance. Country Flame’s warranty requires a properly installed and listed chimney system.
CHIMNEY CONNECTOR
Chimney connectors are also commonly referred to as chimney pipe. Follow the specific chimney manufacturer’s
installation instructions for proper installation. It is important to ensure a good tight seal and proper installation of the
chimney pipe in order to obtain proper chimney draft once the chimney is completed and the stove is operational. The
chimney pipe should have a 6” (150mm) outside diameter for the model O2. The chimney connector should be
constructed of a minimum of 24 MSG black or 25 MSG blue steel. The use of high temperature RTV sealant and self-
tapping screws will be required to attach different sections of chimney connectors together and ultimately to the stove.
FLUE TRANSITION
Many catalytic stove inserts have chimney connections that do not align with an existing chimney system. In order to
make the installer’s job easier, Country Flame provides standard flue transitions (offsets) that make the installation of a
stove simpler. The use of high temperature RTV sealant and self-tapping screws will be needed to secure and seal the flue
transition properly to the stove and chimney system. Contact Country Flame or one of its locale authorized dealers to
obtain more information about flue transitions.
WALL THIMBLE
A wall thimble is a manufactured or site-constructed device installed in combustible walls and ceilings through which the
chimney pipe passes as it is routed through the house. The wall thimble is designed to ensure that combustible wall
material does not self-ignite due to continuous, radiated and sometime excessive heat generated through the chimney. The
wall thimble is a safety device that prevents wall or house fires.
