Interface Signals 11
LEC-BASE
2.1.3 Camera 1 (CAM1)
Table 2-6 lists the pin signals of the Camera1 header, which provides 10-pins, 2 rows, odd/even
pin sequence (1, 2) with 0.079" (2.00mm) pitch. These signals are connected to the camera
control signals at the SMARC connector.
NOTE: The shaded table cells denote ground.
2.1.4 Camera 3 (CAM3)
Table 2-7 lists the pin signals of the Camera 3 header, which provides 10-pins, 2 rows, odd/even
pin sequence (1, 2) with 0.079" (2.00mm) pitch. These signals are connected to the camera
control signals at the SMARC connector.
Table 2-6: Camera 1 Pin Signals (CAM1)
Pin # Signal
1 CSI0_CK+
2 CSI0_CK-
3 CSI0_D0+
4 CSI0_D0-
5 CSI0_D1+
6 Not Connected
7 CSI0_D1-
8 Not Connected
9 GND
10 GND
Table 2-7: Camera 3 Pin Signals (CAM3)
Pin # Signal
1 CAM0_nPWR
2 I2C_CAM_CLK_1.8V
3 Not Connected
4 I2C_CAM_DATA_1.8V
5 Not Connected
6 Not Connected
7 CAM0_nRST_3V over the 3.3V level shifter
8 Not Connected
9 5 Volt
10 Not Connected
