10 Interface Signals
NOTE: The shaded table cells denote power or ground.
2.1.2 Camera 0 (CAM0)
Table 2-5 lists the pin signals of the Camera0 header, which provides 10-pins, 2 rows, odd/even
pin sequence (1, 2) with 0.079" (2.00mm) pitch. These signals are connected directly to the MIPI
CSI camera interface at the SMARC connector.
36 GND
37 GND
38 GND
39 MMC2_D6_3V
40 GND
41 GND
42 GND
43 GND
44 GND
45 MMC2_D7_3V
46 GND
47 GND
48 GND
49 GND
50 GND
51 MMC2_CK_3V
52 GND
53 GND
54 GND
55 GND
56 GND
57 MMC2_CMDD_3V
58 GND
59 GND
60 GND
Table 2-5:Camera 0 Pin Signals (CAM0)
Pin # Signal
1 CSI1_CK+
2 CSI1_CK-
3 CSI1_D0+
4 CSI1_D0-
5 CSI1_D1+
6 CSI1_D1-
7 CSI1_D2+
8 CSI1_D2-
9 CSI1_D3+
10 CSI1_D3-
Table 2-4: SD/eMMC (AFB2) Interface Pin Signals (Continued)
