Express-CVC Page 9
2.4. Audio
¾ Integrated: Intel® HD Audio integrated in NM10
¾ Audio Codec: Realtek ALC888 or 886 on Express-BASE
2.5. Ethernet
¾ Controller: Intel® Ethernet Controller I210
¾ Connection: PCIe x1
¾ Interface: 10/100/1000 GbE connection
2.6. Multi I/O and Storage
¾ USB ports: 8 ports USB 1.1/2.0
¾ SATA ports: 1 ports SATA 3 Gb/s (SATA0)
optional 2 ports SATA 3 Gb/s (SATA0, SATA1) by removing PATA solution
¾ PATA port: single PATA port through Jmicron JM330 SATA to PATA Bridge
2.7. Super I/O (on Carrier using LPC -bus)
¾ Chipset: Winbond W83627HG-AW AND W83627DHG-P
With keyboard A20 and Keyboard RESET line
¾ Parallel Port: LPT1
¾ Serial Ports: COM1/COM2
2.8. GPIO
¾ Chipset: NXP PCA9535
¾ GPO: 4 ports
¾ GPI: 4 ports with interrupt
2.9. SEMA Board Controller
¾ Power Features
o
ATX/AT mode control
o
ECO mode support
o
Emergency Shutdown
o
Power Status Monitoring and Signalling
o
Voltage and Current monitoring
o
Current Monitor
¾ Flat Panel Control
¾ General Purpose I2C
¾ Dual Failsafe BIOS
¾ Watchdog Timer
¾ Smart Fan Control
