3. COM Express Pinouts and Signal Descriptions
The following information is a summary of the most important information regarding pinout and signal description in the official PICMG
COM.0 Rev 2.0 (soon 2.1)
The pinout is noted here to emphazise issues that have not been followed in the past. The following might have small inacuaracies so in
case of doubt the offical design guide of PICMG should be consulted.
3.1. AB/CD Pin Definitions
The Express-CVC is a Type 2 module supporting PCI and PATA IDE on the CD connector.
All pins in the specification are described including those not supported on the Express-CVC.
Those not supported on the Express-CVC module are crossed out
Row A
Row B
Row C
Row D
Pin
Name
Pin
Name
Pin
Name
Pin
Name
A1
GND (FIXED)
B1
GND (FIXED)
C1
GND FIXED)
D1
GND FIXED)
A2
GBE0_MDI3-
B2
GBE0_ACT#
C2
IDE_D7
D2
IDE_D5
A3
GBE0_MDI3+
B3
LPC_FRAME#
C3
IDE_D6
D3
IDE_D10
A4
GBE0_LINK100#
B4
LPC_AD0
C4
IDE_D3
D4
IDE_D11
A5
GBE0_LINK1000#
B5
LPC_AD1
C5
IDE_D15
D5
IDE_D12
A6
GBE0_MDI2-
B6
LPC_AD2
C6
IDE_D8
D6
IDE_D4
A7
GBE0_MDI2+
B7
LPC_AD3
C7
IDE_D9
D7
IDE_D0
A8
GBE0_LINK#
B8
LPC_DRQ0#
C8
IDE_D2
D8
IDE_REQ
A9
GBE0_MDI1-
B9
LPC_DRQ1#
C9
IDE_D13
D9
IDE_IOW#
A10
GBE0_MDI1+
B10
LPC_CLK
C10
IDE_D1
D10
IDE_ACK#
A11
GND (FIXED)
B11
GND (FIXED)
C11
GND (FIXED)
D11
GND (FIXED)
A12
GBE0_MDI0-
B12
PWRBTN#
C12
IDE_D14
D12
IDE_IRQ
A13
GBE0_MDI0+
B13
SMB_CK
C13
IDE_IORDY
D13
IDE_A0
A14
GBE0_CTREF
B14
SMB_DAT
C14
IDE_IOR#
D14
IDE_A1
A15
SUS_S3#
B15
SMB_ALERT#
C15
PCI_PME#
D15
IDE_A2
A16
SATA0_TX+
B16
SATA1_TX+
C16
PCI_GNT2#
D16
IDE_CS1#
A17
SATA0_TX-
B17
SATA1_TX-
C17
PCI_REQ2#
D17
IDE_CS3#
A18
SUS_S4#
B18
SUS_STAT#
C18
PCI_GNT1#
D18
IDE_RESET#
A19
SATA0_RX+
B19
SATA1_RX+
C19
PCI_REQ1#
D19
PCI_GNT3#
A20
SATA0_RX-
B20
SATA1_RX-
C20
PCI_GNT0#
D20
PCI_REQ3#
A21
GND (FIXED)
B21
GND (FIXED)
C21
GND (FIXED)
D21
GND (FIXED)
A22
SATA2_TX+
B22
SATA3_TX+
C22
PCI_REQ0#
D22
PCI_AD1
A23
SATA2_TX-
B23
SATA3_TX-
C23
PCI_RESET#
D23
PCI_AD3
A24
SUS_S5#
B24
PWR_OK
C24
PCI_AD0
D24
PCI_AD5
A25
SATA2_RX+
B25
SATA3_RX+
C25
PCI_AD2
D25
PCI_AD7
A26
SATA2_RX-
B26
SATA3_RX-
C26
PCI_AD4
D26
PCI_C/BE0#
A27
BATLOW#
B27
WDT
C27
PCI_AD6
D27
PCI_AD9
A28
(S)ATA_ACT#
B28
AC/HDA_SDIN2
C28
PCI_AD8
D28
PCI_AD11
A29
AC/HDA_SYNC
B29
AC/HDA_SDIN1
C29
PCI_AD10
D29
PCI_AD13
A30
AC/HDA_RST#
B30
AC/HDA_SDIN0
C30
PCI_AD12
D30
PCI_AD15
A31
GND (FIXED)
B31
GND (FIXED)
C31
GND (FIXED)
D31
GND (FIXED)
A32
AC/HDA_BITCLK
B32
SPKR
C32
PCI_AD14
D32
PCI_PAR
A33
AC/HDA_SDOUT
B33
I2C_CK
C33
PCI_C/BE1#
D33
PCI_SERR#
A34
BIOS_DIS0#
B34
I2C_DAT
C34
PCI_PERR#
D34
PCI_STOP#
A35
THRMTRIP#
B35
THRM#
C35
PCI_LOCK#
D35
PCI_TRDY#
