Page 34 Express-CVC
5.3. I/O Map
Hex Range Device
000-01F DMA controller
020-02D and 030-03F Interrupt controller
02E-02F LPC SIO configuration index/data registers
040-05F Timer
060, 062, 064, 066 Keyboard
061, 063, 065, 067 NMI control and status
070-07F Real Time Clock Controller( bit 7 -NMI mask)
080-091 DMA controller
092 Reset (Bit 0)/ Fast Gate A20 (Bit 1)
93-9F DMA controller
0A0-0B1 and 0B4-0BF Interrupt controller
0B2h APM Control I/O Address
0B3h APM Status I/O Address
0C0-0DF DMA controller
0F0 Co-processor error register
180-181 Default AIM4 SRAM control register (May be remapped)
182-1EF Available
1F0-1F7 Primary IDE Controller (AT Drive)
1FB-22F Available
230 -277 Available
278-27F Reserved for parallel port
280-2F7 Available
2F8-2FF Serial Port 2
300-36F Available
370-377 Alt. Floppy Disk Controller
378-37F Reserved for parallel port
380-3AF Available
3B0-3BB and 3BF Mono/VGA mode video
3BC-3BE Reserved for parallel port
3C0-3DF VGA registers
3E0-3EF Available
3F0-3F7 Primary Floppy disk controller
3F8-3FF Serial port 1
4D0 Master PIC Edge/Level Trigger register
4D1 Slave PIC Edge/Level Trigger register
CF8-CFB PCI configuration address register (32 bit I/O only)
CF9 Reset Control register (8 bit I/O)
