3.4.4. Module Type Definition
3.4.5. Power and Ground
Signal Pin Description I/O PU/PD Comment
VCC_12V C104-C109
D104-D109
Primary power input: +12V nominal. All available VCC_12V pins on
the connector(s) shall be used. P 5~ 20 V
GND C1, C11, C21, C31, C41,
C51, C60, C70, C76, C80,
C84, C87, C90, C93, C96,
C100, C103, C110, D1,
D11, D21, D31, D41, D51,
D60, D67, D70, D76, D80,
D84, D87, D90, D93, D96,
D100, D103, D110 Ground - DC power and signal and AC signal return path.
All available GND connector pins shall be used and tied to carrier
board GND plane.
P
Pin Pin
Name SDVO DP HDMI \ DVI
TYPE0#
TYPE1#
TYPE2# C54
C57
D57 The TYPE pins indicate to the Carrier Board the Pin-out Type that is implemented on the
module. The pins are tied on the module to either ground (GND) or are no-connects (NC). For
Pinout Type 1, these pins are don’t care (X).
TYPE2# TYPE1# TYPE0#
X
X X Pinout Type 1
NC NC NC Pinout Type 2
NC NC GND Pinout Type 3 (no IDE)
NC GND NC Pinout Type 4 (no PCI)
NC GND GND Pinout Type 5 (no IDE, no PCI)
GND NC NC Pinout Type 6 (no IDE, no PCI)
The Carrier Board should implement combinatorial logic that monitors the module TYPE pins
and keeps power off (e.g deactivates the ATX_ON signal for an ATX power supply) if an
incompatible module pin-out type is detected. The Carrier Board logic may also implement a
fault indicator such as an LED.
This is a Type 2
module
